Key Product Data
Model: 2711P-RDT10C
Brand: Allen-Bradley
Manufacturer: Rockwell Automation
Product Type: PanelView Plus Display Module
Product Family: PanelView Plus 1000
UPC: 611320817102
Display Size: 10.4 inches
Display Technology: Color TFT LCD
Display Resolution: 640 × 480 pixels
Display Area: 211 × 158 mm
Operator Input: Analog resistive touchscreen
Display Luminance: 300 cd/m²
Backlight: CCFL
Input Voltage: 85–264 V AC
Power Consumption: 39 W typical; 70 W maximum
Panel Cutout: 224 × 305 mm
Overall Dimensions: 329 × 248 × 55 mm (W × H × D)
Approximate Weight: 2.6 kg
Front Protection: IP65
Lifecycle Status: Discontinued
Discontinuation Date: December 30, 2021
Product Introduction
The Allen-Bradley 2711P-RDT10C is a color touchscreen display module designed for the PanelView Plus 1000 operator interface platform. It features a 10.4-inch TFT LCD with a 640 × 480 resolution and analog resistive touch input, providing a visual interface for industrial machine operation and process monitoring.
This catalog number identifies the display module rather than a complete PanelView terminal. It is relevant when replacing a damaged display assembly in compatible existing equipment, where retaining the installed operator interface configuration may be preferable to replacing the entire terminal.
Can't find the version you need?
Display and Operator Interaction
The 10.4-inch color screen presents graphical operating information through a 211 × 158 mm display area. Its analog resistive touchscreen allows operators to interact with on-screen controls and interface elements without a separate physical keypad on this display variant.
The display has a specified luminance of 300 cd/m² and uses a CCFL backlight. The 640 × 480 pixel resolution corresponds to the standard display format of this PanelView Plus 1000 module.
Electrical and Physical Characteristics
The module's listed AC input voltage range is 85–264 V. Power consumption is approximately 39 W under typical conditions, with a maximum rating of 70 W.
For panel replacement planning, the specified cutout is 224 × 305 mm, while the complete module measures approximately 329 mm wide, 248 mm high and 55 mm deep. The front protection rating is IP65; enclosure protection and installation conditions should be assessed against the requirements of the existing panel assembly.
Replacement and Compatibility Considerations
The 2711P-RDT10C belongs to the earlier PanelView Plus 1000 display-module family. Before ordering, verify the installed display's complete catalog number and confirm that the existing terminal belongs to a compatible PanelView Plus configuration.
This part number identifies the touchscreen color display variant. It should not be confused with keypad-only or combined keypad-and-touch display modules, which use different catalog numbers.
Product Lifecycle and Spare-Part Procurement
Rockwell Automation lists the 2711P-RDT10C as discontinued, with the discontinuation effective December 30, 2021. The manufacturer lists an engineering replacement category, so buyers assessing a replacement should check the proposed alternative against the existing terminal configuration rather than assume that a newer display module is a direct drop-in substitute.
For sourcing, use 2711P-RDT10C as the primary model identifier and UPC 611320817102 as an additional product reference. Matching the complete catalog number helps distinguish this 10.4-inch touchscreen display from other PanelView Plus modules.
