ACS880-01-07A2-3+E202+K458+N2005+R700 is a configured ABB ACS880-01 low-voltage AC industrial drive based on the wall-mounted single-drive platform. The base drive is rated for 3 kW, 8.0 A and 400 V, and its complete order designation identifies additional hardware, communication, software and documentation selections. ABB lists the base model as an LV AC industrial wall-mounted single drive.
For spare-part identification, the complete option string is important. The registered Product ID is 3AUA0000107988, while the EAN is 6438177558187. These identifiers correspond to the base ACS880-01-07A2-3 product.
Identification at a Glance
| Item | Details |
|---|---|
| Brand | ABB |
| Product family | ACS880 |
| Base type | ACS880-01-07A2-3 |
| Complete designation | ACS880-01-07A2-3+E202+K458+N2005+R700 |
| Product ID | 3AUA0000107988 |
| EAN | 6438177558187 |
| Product type | LV AC industrial wall-mounted single drive |
| Rated motor power | 3 kW |
| Rated current | 8.0 A |
| Rated voltage class | 400 V |
| Frame size | R1 |
The ACS880-01-07A2-3 is identified by ABB as an R1-frame drive in the ACS880-01 range. ABB documentation also gives the R1 mechanical envelope as approximately 409 × 155 × 226 mm, with a listed weight of about 7 kg for the drive configuration.
What the Full Order Code Tells You
The suffixes should not be treated as part of the basic model number. They identify the particular configuration supplied with the drive.
| Option | Confirmed meaning |
|---|---|
| +E202 | EMC filter for first environment, TN grounded system, Category C2 |
| +K458 | FSCA-01 RS-485 adapter for Modbus RTU |
| +N2005 | Additional configured option code; exact application designation should be matched against the original ABB order record |
| +R700 | Full set of printed manuals in English |
ABB's ACS880 documentation identifies E202 as the EMC filter option for a first environment, TN grounded system, Category C2. The same documentation identifies K458 as the FSCA-01 RS-485 / Modbus RTU adapter. ABB also defines R700 as the English-language printed manual set.
For N2005, ABB's currently accessible public documentation does not provide enough direct evidence to safely expand the code for this exact configured product. It is therefore better to retain +N2005 exactly as supplied rather than attaching an unsupported application description.
Drive Ratings
The base ACS880-01-07A2-3 belongs to the R1-frame 400 V class of ACS880-01 industrial drives.
| Characteristic | Value |
|---|---|
| Supply voltage class | 400 V |
| Nominal motor power | 3 kW |
| Product-designation current | 8.0 A |
| Frame | R1 |
| Drive construction | Wall-mounted single drive |
| Drive family | ACS880-01 |
| Control technology | Direct Torque Control (DTC) platform |
ABB's current product information gives the catalog rating as 3 kW, 8.0 A, 400 V. Separate ABB drive-selection material identifies the ACS880-01-07A2-3 as an R1-frame, 3 kW model.
EMC and Communication Configuration
The +E202 selection is particularly relevant when identifying an existing drive because it changes the supplied EMC configuration from the basic drive. ABB specifies E202 for a first environment, restricted distribution, Category C2, TN grounded system.
The +K458 option adds the FSCA-01 RS-485 adapter, providing Modbus RTU connectivity. This is different from ABB's Ethernet-based K473/K475 options and should therefore be retained when matching a replacement drive against an installed unit.
Can't find the version you need?
Mechanical Format
The ACS880-01 is ABB's wall-mounted single-drive format, although the platform can also be installed in a cabinet depending on the selected configuration. ABB describes the ACS880-01 as a compact standalone drive family with enclosure options extending up to IP55 across the product range.
For the R1 frame represented by ACS880-01-07A2-3, ABB's published dimensional data gives:
- Height: approximately 409 mm
- Width: approximately 155 mm
- Depth: approximately 226 mm
- Weight: approximately 7 kg
Application Range
The ACS880-01 family is intended for industrial motor-driven equipment. ABB lists applications including conveyors, mixers, compressors, pumps, fans, centrifuges, cranes, extruders, winches, winders, elevators and other variable- or constant-torque machinery.
For procurement purposes, these application references are useful mainly for identifying the drive family and installed-equipment context. The exact replacement should still be matched by the complete type designation and option string rather than by application name alone.
Configuration and Replacement Notes
When identifying this unit for replacement or spare-part procurement, use the following hierarchy:
1. Complete configured designation
ACS880-01-07A2-3+E202+K458+N2005+R700
2. Base drive type
ACS880-01-07A2-3
3. ABB Product ID
3AUA0000107988
4. EAN
6438177558187
5. Option combination
E202 + K458 + N2005 + R700
This distinction matters because an ACS880-01-07A2-3 without the same option combination is not necessarily an identical configured replacement.
Alternative Names
The following forms may appear in purchasing records, equipment lists or search queries:
- ACS880-01-07A2-3
- ACS8800107A23
- ACS880 01 07A2 3
- 3AUA0000107988
- ACS880-01-07A2-3 ABB
- ACS880-01-07A2-3+E202
- ACS880-01-07A2-3+K458
- ACS880-01-07A2-3+E202+K458
- ACS880-01-07A2-3+N2005
- ACS880-01-07A2-3+R700
- ACS880-01-07A2-3 E202 K458
- ACS880-01-07A2-3 E202 K458 N2005
- 3AUA0000107988 ABB drive
- ABB ACS880 3 kW drive
- ABB ACS880 400 V drive
- ABB ACS880 R1 drive
- ACS880-01 R1 3 kW
- ABB LV AC industrial drive 3 kW
- ABB 8.0 A ACS880 drive
- 6438177558187
Frequently Asked Questions
What is the ABB Product ID for this drive?
The ABB Product ID is 3AUA0000107988. The corresponding EAN is 6438177558187.
What is the base model behind the complete designation?
The base model is ACS880-01-07A2-3. The +E202+K458+N2005+R700 portion identifies additional options and documentation associated with the configured unit.
What does +K458 indicate?
+K458 identifies the ABB FSCA-01 RS-485 adapter module for Modbus RTU.
What does +E202 indicate?
+E202 is ABB's EMC filter option for a first environment, TN grounded system, Category C2.
What does +R700 mean?
+R700 denotes the full set of printed manuals in English.
What motor power is associated with ACS880-01-07A2-3?
ABB lists the base ACS880-01-07A2-3 at 3 kW with an 8.0 A catalog rating and 400 V class.
Is ACS880-01-07A2-3 a wall-mounted drive?
Yes. ABB classifies the ACS880-01 as a wall-mounted single-drive family, with cabinet installation also possible depending on configuration.
Should the option codes be included when replacing this drive?
Yes. For an exact spare-part match, the complete designation ACS880-01-07A2-3+E202+K458+N2005+R700 should be retained rather than searching only for the base model.
Procurement Reference
Primary identification: ACS880-01-07A2-3+E202+K458+N2005+R700
ABB Product ID: 3AUA0000107988
EAN: 6438177558187
Base model: ACS880-01-07A2-3
Rated power: 3 kW
Rated current: 8.0 A
Voltage class: 400 V
Frame: R1
Options: E202 / K458 / N2005 / R700
Category: Variable Speed Drive Systems
For an existing installation, matching the complete option string together with Product ID provides a more reliable identification basis than matching the ACS880 series name alone.
